PREPARATION
12 F-050408L
HOW TO ADJUST THE HANDLE HEIGHT
The handle bracket has two assembly posi-
tions. A HIGH and a LOW position (Figure 4).
The HIGH position will raise the handle ap-
proximately four inches.
Figure 4
LOW
ЗЗ
ЗЗ
ЗЗ
ЗЗ
HIGH
1. Remove the knobs and bolts from the
right and left handle brackets (Figure 5).
2. To raise the handle, mount the lower han-
dle in the HIGH position shown in Figure 6.
3. To lower the handle, mount the lower han-
dle in the LOW position shown in Figure 7.
4. Attach the lower handle to the handle
brackets with the bolts and knobs.
(Figure 5).
Knob
Lower
Handle
Handle
Bracket
Upper Handle
Figure 5
Knob
Bolt
Figure 6
HIGH
Position
Handle
Bracket
Figure 7
LOW
Position
Handle
Bracket
