Install 3 screws to install light pan.
23
Connect plug from fan to switch
house plug.
20
Install by twisting clockwise, add 1
screw removed step 18 to switch
housing plate. Tighten the 3 screws
securely.
19
Connect white wire from fan to white
wire from light fixture. Then plug
blue wire from fan to black wire from
light fixture.
22
Loosen the pre installed screws of
switch housing plate.
Install 75 watt halogen bulb. Do not
touch bulb surface as oily residue
from skin can cause the bulb to
explode.
24
21
Attach glass by locating dimples in
light fixture with the groves in glass
and twisting clockwise till tight.
25
