Morphy Richards 29005 - Manual

Illustration
Stereo cd alarm
clock radio
29005 OPERATING INSTRUCTIONS
Electrical requirements
Check the voltage on the rating plate of your clock radio corresponds with
your house electricity supply which must be A.C. (Alternating current).
If the socket outlets in your home are not suitable for the plug supplied with
this appliance the plug should be removed and the appropriate one fitted.
IMP0RTANT : THE PLUG REMOVED FROM THE MAINS LEAD, IF SEVERED,
MUST BE DESTROYED AS A PLUG WITH A BARED FLEXIBLE CORD IS
HAZARDOUS IF ENGAGED INTO A LIVE SOCKET OUTLET.
Should the fuse in the 13 amp plug require changing a 3 amp BS1362 fuse
must be fitted.
Battery back-up facility (unit will work without a battery being fitted)
Your cd alarm clock radio is equipped with a battery back-up facility.
1
Remove the battery compartment cover (underneath the unit) by
sliding the cover off.
2 Insert a battery size 9 volts PP3/6LR61 (Ensure battery is inserted correctly)
3 Replace the battery compartment cover.
Should a power interruption occur the clock will continue to run, however, time
keeping will not be accurate. The display will be extinguished to conserve battery
life but the memory will retain details of the clock time and alarm settings.
If the optional battery is not installed in case of the AC power failure the clock will
reset to 12:00 when the power is restored. You will need to reset the clock
and alarm.
Battery back-up is designed to operate for a short period only.
If the unit is not to be used for a prolonged period, remove the battery to
avoid battery leakage.
In the interests of environmental safety : dispose of batteries safely.
Speakers (speakers are detachable)
Open the speaker wire compartment located underneath the unit and unravel the
speaker wire. Detach the speakers and position where required. Wind up excess
wire around pegs on the underneath of the unit. Close the speaker wire
compartment door.
P.2
P.3 P.4
Setting the clock time
1 While holding down the TIME button, press the or to set the
desired time.
2 Release the button to save time setting.
Radio operation
FM wire aerial
To obtain the maximum FM reception fully extend the wire FM aerial (which is
located at the rear of the unit) and alter the direction of the wire for best results.
The aerial for the MW waveband is located inside the unit. To obtain the
maximum MW reception rotate the clock radio.
1 Slide the FUNCTION SELECTOR switch to select MW or FM.
2 Press the POWER on/off button.
3 Adjust the VOLUME control to a suitable level.
4 Slowly adjust the TUNING control to select your desired station. The
FM LED indicator will light up when an FM stereo signal is received.
5 To switch off the radio, press the POWER on/off button.
To play compact disc
1 Press the power on/off button.
2 Open the cd door using cd open tab, load a disc in the cd compartment. Push
down gently on the door to close.
3 Select the cd mode by switching the function selector to cd.
4 Press the play/pause button. The display will show the track number when
you begin to play a cd. After a few seconds, the display reverts to the
current time.
Note : The same button can be used to momentarily interrupt playback. The
track number will flash until the
button is pressed again.
5 Adjust the volume control until the desired level is reached.
6 Press the stop button to stop playback.
7 To switch off the cd, press the power on/off button.
1
2
2
3
4
5
6
7
8
9
10
11
12
13
16
17
14
15 20
21
18
19 24
25
22
23
26
○
○
27
Location of controls
1 Cd open tab
2 Speakers (detachable)
3 Pm indicator
4 Program indicator
5 Random indicator
6 Repeat indicator
7 Power indicator
8 Alarm 1 indicator
9 Dial scale with pointer
10 Tuning control
11 Alarm function selector switch
12 Alarm 1 and 2 selector switch
13 Snooze button
14 Play/pause button
button: to switch unit on and
start playback. To momentarily stop playback
15 Play mode/program button
16 PTS button: to select your favourite cd track for waking
up to music
17 Alarm 1 button: to set alarm 1
18 button: to stop cd playback
19 MIN Skip/fast search/selection ( backward):
-to skip cd tracks and for minute setting of alarm clock
functions and time.
(quick selection: press and hold
normal selection: press repeatedly)
20 Repeat button: for continuous
playback
21 Alarm 2 button: to set alarm 2.
22 Power on/off button: to turn radio,cd
and alarm on/off
23 HOUR Skip/fast search/selection
( forward): -to skip cd tracks
and for fast search within a track
-for setting of hour, for time and
alarm clock functions
quick selection: press and hold
normal selection: press repeatedly
24 Sleep button
25 Time button
26 FM wire aerial
27 Function selector switch
28 Volume control
29 Earphone jack
30 Battery compartment
31 Alarm 2 indicator
32 FM stereo indicator
28
29
30 31
32
