PAGE 15
REAR PANEL:
(Continued)
REVERB REMOTE JACK:
The Reverb feature contains a Remote Switch jack that allows you to control the Reverb effect from
a separate footswitch. The 1/4” jack is located on the underside of the chassis just below where the SLAVE jack is located on the
extreme right side of the Back Panel.
Connecting any tip-to-ground, latching-type footswitch will allow you to toggle on and off the Reverb effect.
Use a shielded cable for this application. You should be able to fi nd this type of footswitch at most music
stores or, you can call our Customer Service department and order one for a nominal charge.
SLAVE
SPEAKERS
HAND BUILT IN PETALUMA CA.
8 OHM
4 OHM
4 OHM
REMOTE
FOOTSWITCH JACK
REST AREA
