100 Series

The 100 Series utilises bass drivers featuring the advanced MMP

®

II cone technology together with Monitor Audio’s trade

mark C-CAM

®

gold dome tweeter. The MMP

®

II (Metal Matrix Polymer) cone material uses a high-pressure injection moulding

process to achieve different thicknesses at critical points in the cone geometry.

High frequency performance has been improved by the evolution of the C-CAM

®

tweeter. The new tweeter utilises a pivoting

action to provide optimum imaging and flexible set-up options. High frequency level control is provided to offer a degree of
balance adjustment once installation is completed. See page 2.

Introduction

Please read this installation guide carefully before proceeding.

ALSO AVAILABLE: Pre-construction brackets. These are for use when installing any Custom Installation product before the
plaster board/ rock wall, is fitted. They show the location of the speakers to the builder, allow pre-wiring and give them
a solid secure edge to cut around. Please ask your dealer about these brackets and to confirm which is correct for your
installation.

PLEASE CHECK YOU HAVE THE FOLLOWING ITEMS IN THIS KIT BEFORE PROCEEDING:

1 x Complete speaker & tweeter assembly.

1 x Grille (which can be painted).

1 x Mounting cut out template (in packaging).

1 x Plastic paint mask (for covering the baffle while painting the frame).

1 x Self adhesive grille membrane scrim (to be attached to the inside the grille after it has been painted).

1 x Guarantee card in this manual.

Prior to Installation Check the Following:

Please check the minimum depth of the product (according to the specifications sheet) is correct for the assembly to
fit into recess.

The fixing clamps require a minimum of 25mm (1 Inch) of surface area around the cut-out hole to ensure a secure

fixing!

100 Series loudspeakers are splash and moisture proof, so they can be used in bathrooms, pool areas, etc. DO NOT
allow them to be in constant contact with water/moisture.

The fixing clamps will operate on ceilings/walls with a minimum thickness of 9mm (3/8 Inches) to a maximum depth
of 32mm (1¼ Inches).

Do not attempt to fix these speakers to your ceiling/wall if you are unsure of your ability to provide a secure and safe
fixing. IF IN DOUBT CONTACT YOUR LOCAL AUTHORISED MONITOR AUDIO DEALER.

Ensure that there are no water pipes, air ducts or electricity cables running immediately behind the cut out area!

Please work from secure steps or scaffold and avoid trailing wires for your safety and those around you.

Always turn off the amplifier or other devices in the system when connecting these speakers.

Installation guide

Frequency Response

60Hz - 25KHz

Impedance (nominal)

6+6 Ohms

Sensitivity (1W@1M)

89 dB

Maximum SPL

107.9 dBA

Power Handling (R.M.S)

65 W

Recommended Amp

10 - 65 W

Driver

1 x 6.5” MMP

®

II

‘cone bass driver

2 x 1” C-CAM

®

pivoting gold

dome tweeter

Overall Diameter

250mm (9 13/16 inch)

Overall Depth

117 mm (4 5/8 inch)

Cut-out Hole Diameter

211mm (8 5/16 inch)

Mounting Depth

112 mm (4 7/16 inch)

Fixing Type

3 position Tri-Grip

dog fixings

Cable Connection

Gold plated ‘push’ type terminals

Construction Material

Mineral filled ABS plastic (UL94-VO
rated, RoHS compliant)
Pre-construction Bracket

CB6 (Purple)

Weight Kg (lb)
2.08Kg (4.6 lbs)

C165-T2

Frequency Response

60Hz - 25KHz

Impedance (nominal)

6 Ohms

Sensitivity (1W@1M)

88.5 dB

Maximum SPL

107.4 dBA

Power Handling (R.M.S)

65 W

Recommended Amp

10 - 65 W

Driver

1 x 6.5” MMP

®

II

cone bass driver

1 x 1” C-CAM

®

pivoting gold

dome tweeter

Controls
+3db / 0db / -3db High
Frequency Level Switch

Overall Diameter

250 mm (9 13/16 inch)

Overall Depth

117 mm (4 5/8 inch)

Cut-out Hole Diameter

211 mm (8 5/16 inch)

Mounting Depth

112 mm (4 7/16 inch)

Fixing Type

3 position Tri-Grip

dog fixings

Cable Connection

Gold plated ‘push’ type terminals

Construction Material

Mineral filled ABS plastic (UL94-VO
rated, RoHS compliant)
Pre-construction Bracket

CB6 (Purple)

Weight Kg (lb)
1.92 Kg (4.2 lbs)

C165

Frequency Response

50Hz - 25KHz

Impedance (nominal)

6 Ohms

Sensitivity (1W@1M)

90 dB

Maximum SPL

111.6 dBA

Power Handling (R.M.S)

120 W

Recommended Amp

15 - 120 W

Driver

1 x 8” MMP

®

II

cone bass driver

1 x 1” C-CAM

®

pivoting gold

dome tweeter

Controls
+3db / 0db / -3db High
Frequency Level Switch

Overall Diameter

286 mm (11 1/4 inch)

Overall Depth

124 mm (4 7/8 inch)

Cut-out Hole Diameter

247 mm (9 3/4 inch)

Mounting Depth

119 mm (4 11/16 inch)

Fixing Type

3 position Tri-Grip

dog fixings

Cable Connection

Gold plated ‘push’ type terminals

Construction Material

Mineral filled ABS plastic (UL94-VO
rated, RoHS compliant)

Pre-construction Bracket

CB8 (Green)

Weight Kg (lb)
2.72 Kg (6 lbs)

C180

Frequency Response

50Hz - 25KHz

Impedance (nominal)

6+6 Ohms

Sensitivity (1W@1M)

90 dB

Maximum SPL

111.6 dBA

Power Handling (R.M.S)

120 W

Recommended Amp

15 - 120 W

Driver

1 x 8” MMP

®

II

‘cone bass driver

2 x 1” C-CAM

®

pivoting gold

dome tweeter

Controls
+3db / 0db / -3db High
Frequency Level Switch

Overall Diameter

286 mm (11 1/4 inch)

Overall Depth

124 mm (4 7/8 inch)

Cut-out Hole Diameter

247 mm (9 3/4 inch)

Mounting Depth

119 mm (4 11/16 inch)

Fixing Type

3 position Tri-Grip

dog fixings

Cable Connection

Gold plated ‘push’ type terminals

Construction Material

Mineral filled ABS plastic (UL94-VO
rated, RoHS compliant)

Pre-construction Bracket

CB8 (Green)

Weight Kg (lb)
3 Kg (6.6 lbs)

C180-T2

Declaration of Conformity

We, Monitor Audio Ltd.
24 Brook Road
Rayleigh
Essex
SS6 7XL
England

Declare in own responsibility, that the products described in this manual are in
compliance with technical standards:
EN 50082-1 : 1998
EN 55013 : 2001
EN 50020 : 2002

Dean Hartley (Technical Director)

Monitor Audio Ltd

England

Q u i c k T i m e ™

a n d

a

d e c o m p r e s s o r

a r e

n e e d e d

t o

s e e

t h i s

p i c t u r e .

Declarat ion of Co nformity

We , Monitor Au dio Ltd.

24 Brook Road

Rayleig h

Esse x

SS6 7XL

Eng land

Declare in own resp onsibi lity, that the produ cts descri bed in this ma nual are in

compl iance with technica l standard s:

EN 50082 -1 :

1998

EN 5501 3 :

2001

EN 5002 0 :

200 2

Dean Ha rtley (Tech nical Director)

Mon itor Audio Ltd

Eng land

Frequency Response

60Hz - 25KHz

Impedance (nominal)

6 Ohms

Sensitivity (1W@1M)

88.5 dB

Maximum SPL

107.4 dBA

Power Handling (R.M.S)

65 W

Recommended Amp

10 - 65 W

Driver

1 x 6.5” MMP

®

II

‘cone bass driver

1 x 1” C-CAM

®

pivoting gold

dome tweeter

Controls
+3db / 0db / -3db High
Frequency Level Switch

Overall Dimensions

H 368 x W 248.5mm
(14 1/2 x 9 13/16 inch)

Overall Depth

94.5mm (3 3/4 inch)

Cut-out Hole Size

H 332 x W 212.5mm
(13 1/16 x 8 3/8 inch)

Mounting Depth

90 mm (3 9/16 inch)

Fixing Type

6 position Tri-Grip

dog fixings

Cable Connection

Gold plated ‘push’ type terminals

Construction Material

Mineral filled ABS plastic (UL94-VO
rated, RoHS compliant)

Pre-construction Bracket

WB6 (purple)

Weight Kg (lb)
2.24 Kg (4.9 lbs)

W165

Frequency Response

50Hz - 25KHz

Impedance (nominal)

6 Ohms

Sensitivity (1W@1M)

90 dB

Maximum SPL

111.6 dBA

Power Handling (R.M.S)

120 W

Recommended Amp

15 - 120 W

Driver

1 x 8” MMP

®

II

‘cone bass driver

1 x 1” C-CAM

®

pivoting gold

dome tweeter

Controls
+3db / 0db / -3db High
Frequency Level Switch

Overall Dimensions

H 423 x W 270mm
(16 5/8 x 10 5/8 inch)

Overall Depth

103 mm (4 1/16 inch)

Cut-out Hole Size
H 387 x W 234mm
(15 1/4 x 9 3/16 inch)

Mounting Depth

98.5 mm (3 7/8 inch)

Fixing Type

6 position Tri-Grip

dog fixings

Cable Connection

Gold plated ‘push’ type terminals

Construction Material

Mineral filled ABS plastic (UL94-VO
rated, RoHS compliant)

Pre-construction Bracket

WB8 (Green)

Weight Kg (lb)
3.08 Kg (6.8 lbs)

W180
