SECTION 1
DESCRIPTION
1
I. MODEL IDENTIFICATION
The Middleby Marshall PS528-Series may be used
either as a single oven or stacked for use as double or
triple ovens.
A single PS528-Series Oven (Figure 1-1) is mounted on a
base pad with legs. A double oven (Figure 1-2) consists
of two,
stacked, single ovens. A triple oven (Figure 1-3)
consists of three stacked single ovens. The lower oven
is mounted on a base pad with stacking pins.
On a double or triple oven, the ovens operate indepen-
dently. All ovens use identical controls and components.
One oven can be cleaned or serviced, while the others
are operating.
SECTION 1
DESCRIPTION
Figure 1-1. Single PS528 Oven
Figure 1-2. Double PS528 Oven
Figure 1-3. Triple PS528 Oven
