Fig. 2: The AutoStar
Handbox (see page 10).
Fig. 1c: The battery compartment.
Fig. 1b : The computer control panel:
A - HBX port; B - LED; C - On/Off;
D - AUX port.
Fig. 3: The tripod.
21. AutoStar
22. Tripod bubble level
23. Base
24. Handle
25. Adjustable legs
26. Locking ring
27. Leg braces/accessory holders
28. Leg locks
29. Bubble level/compass
30. Flip Barlow
