Makita LS1013 - Manual (Page 15)

15
Example:
In the case of cutting 52/38° type crown
molding for position (1) in Fig. A:
• Tilt and secure bevel angle setting to
33.9° RIGHT.
• Adjust and secure miter angle setting to
31.6° RIGHT.
• Lay crown molding with its broad back
(hidden) surface down on the turn base
with its WALL CONTACT EDGE against
the guide fence on the saw.
• The finished piece to be used will
always be on the RIGHT side of the
blade after the cut has been made.
Molding
position in
Fig. A
Molding edge against
guide fence
Finished piece
(1)
Ceiling contact edge should
be against guide fence.
(2)
(3)
(4)
For
outside
corner
Finished piece
will be on the
Left side of
blade.
Finished piece
will be on the
Right side of
blade.
For inside
corner
Wall contact edge should be
against guide fence.
Table (B)
Wall contact edge should be
against guide fence.
006364
