Description of the appliance
The DA-8 Extractor draws cooking va-
pors in through the grease filter
c and
exhausts them to the outside.
b Ventilation grill
c
Grease filter
d 5’’ (120 mm) diameter exhaust
connection
e
Extraction warning label
f Control knob
g
Control panel
Data plate
Because the data plate is no longer
visible once the appliance has been in-
stalled, a 2nd data plate is supplied. It
should be placed into the space pro-
vided on page 11 of these instructions.
Do not install the DA 8-2 directly
next to a gas hob.
