113 Instrument cluster
Technical
data
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
1 Knob for instrument cluster illumination,
see page 114
2 Engine malfunction indicator lamp, see page 302
3 Brake fluid low, parking brake engaged,
see page 313
4 Supplemental restraint system (SRS) malfunction
indicator lamp, see page 305
5 Coolant temperature gauge, see page 115
6 Outside temperature indicator, see page 115
7 Fuel gauge with reserve warning lamp, see page 305
8 Left turn signal indicator lamp, see combination
switch, see page 162
9 Speedometer, see page 116
10 Electronic stability program (ESP) warning lamp,
system is adjusting to road conditions, see page 307
11 Distance warning lamp – vehicles with Distronic
(DTR), distance to the vehicle ahead is insufficient,
see page 272 and 307
Vehicles without Distronic: It illuminates with the
electronic key in starter switch position 2. It should
go out when the engine is running.
12 Multifunction display, see page 118
Malfunction and warning messages in the
multifunction display, see page 309
13 Trip odometer, see page 117 and 122
14 Main odometer, see page 122
15 Right turn signal indicator lamp, see combination
switch, page 162
16 Tachometer, see page 117
17 Gear range indicator display, see selector lever
positions, page 240
18 Digital clock
To set the time, see COMAND operator’s manual
19 Antilock brake system (ABS) malfunction indicator
lamp, see page 306
20 High beam headlamp indicator,
see exterior lamp switch on page 158, and
combination switch on page 162
21 Fasten seat belts, see page 308
22 Reset button J, see page 114 and 117
