CAT-92226B page 2 of 2
FRONT VIEW SIDE VIEW
BOTTOM VIEW
4-1/2 in.
(114 mm)
M U R P
M U R
H Y
S WI CH G A G E ®
P.S.I.
M
U R P
M
U R
H Y
S WI CH G A G E ®
F
6-31/64 in.
(165 mm)
Mounting
Bracket
15/16 in. (24 mm)
2 places
5/8 in. (16 mm)
diameter 2 places
3/4 in.
(19 mm)
diameter
knockout
Emergency
Stop Button
2-1/16 in. (52 mm)
diameter knockout
7/8 in. (22 mm) Hole for
Customer Supplied/installed
Key Switch
Optional Bracket Mounting Holes
5/16 in. (8 mm) diameter 6 places
Shockmounts
518PH
Magnetic Switch
7-23/64 in.
(187 mm)
5-3/4 in.
(146 mm)
15-13/64 in.
(386 mm)
4-1/8 in.
(105 mm)
Removable
Back Cover
Removable
Back Cover
Dimensions
