Maxus PW2515 User Manual
Page 12

5
6
7
8
1
2
3
4
39
11
12
16
17
18
19
13
14
15
20
21
22
23
28
29
24
25
26
10
9
27
30
31
32
37
33
34
35
36
38*
Ref.
Description
Part
Qty.
No.
Number
12
Pressure Washer
Replacement Parts List — Pump
PM341000SJ
For Replacement Parts, Call 1-800-330-0712
Please provide following information:
- Model number
- Serial number (if any)
- Part description and number as shown in parts list
Address parts correspondence to:
Campbell Hausfeld
Attn: Customer Service
100 Mundy Memorial Drive
Mt. Juliet, TN 37122
■ Housing assembly (Includes one each of items 1-5)
PM255230SV
1
● Unloader assembly (Includes one each of items 7-10 and 26)
PM344900SV
1
◆ Oil seal kit (Includes three each of item 12)
PM256500SV
1
▼ Piston guide kit (Includes three each of items 13-15)
PM344905SV
1
▲ Water seal kit (Includes three each of item 16)
PM344910SV
1
★ Outlet valve kit (Includes three each of items 21 and 22)
PM064304SV
1
▲
▲
Inlet valve kit (Includes three each of items 17 and 18)
PM064740SV
1
◆
◆
Valve cap kit (Includes three each of item 23)
PM064750SV
1
■
■
O-ring kit (Includes three each of items 17 and 21
and one each of items 25 and 33)
PM058000SV
1
●
●
Detergent injector kit (Includes one each of items 27-29)
PM064305SV
1
▼
▼
Piston kit (Includes three each of items 32 and 34)
PM344920SV
1
★
★
Needle bearing kit (Includes one each of items 35-37)
PM041840SV
1
Notes
* Available Separately
Oil capacity: 4 fl. oz.
OIl type: SAE 30W (non-detergent)
PART
SERVICE KITS
NUMBER
QTY.
TORQUE SPECIFICATIONS
(
in-lbs)
Ref. No. Description
Torque
6
Thermal relief valve 110
11
Screw
96
19
Head bolt
96
23
Valve cap
240
21
O-ring
★
■
■
–
22
Outlet valve assembly
★
–
23
Valve cap
◆
◆
–
24
Plug
PM064301SV
1
25
■
■
O-ring
PM041870SV
1
26
● Chemical injector assembly
PM341015SV
1
27
Spring
●
●
–
28
Ball
●
●
–
29
O-ring and hose barb
●
●
–
30
Screw
PM064302SV
1
31
Piston body
PM341020SV
1
32
Piston spring
▼
▼
–
33
O-ring, 85 x 2.5
■
■
–
34
Piston
▼
▼
–
35
Thrust shoe
★
★
–
36
Needle bearing
★
★
–
37
Bearing disk
★
★
–
38*
Bolt
MJ101211AV
3
39
Brass swivel assembly
PM041360SV
1
Ref.
Description
Part
Qty.
No.
Number
1
Dust ring
■
–
2
Pump housing
■
–
3
Oil seal ring
■
–
4
Bearing
■
–
5
Wobble plate
■
–
6
Thermal relief valve
PM005405SV
1
7
Unloader valve body assembly
●
–
8
Body guide assembly
●
–
9
Check valve body assembly
●
–
10
Check valve spring
●
1
11
Screw
PM007500SV
2
12
Oil seal
◆
–
13
Oil seal spacer
▼
–
14
Seat seal ring
▼
–
15
Anti-extrusion ring
▼
–
16
Water seal
▲
–
17
O-ring
▲
▲ ■
■
–
18
Suction valve
▲
▲
–
19
Head bolt
PM025100SV
4
20
Head, 12 mm
PM255240SV
1
