A AA AAC P C P C P C P C Power Connection ower Connection ower Connection ower Connection ower Connection
Plug in AC mains only after all Plug in AC mains only after all Plug in AC mains only after all Plug in AC mains only after all Plug in AC mains only after all
signal connections have been
signal connections have been signal connections have been signal connections have been signal connections have been
made and you have verified that made and you have verified that made and you have verified that made and you have verified that made and you have verified that
both amplifiers are switched off.
both amplifiers are switched off. both amplifiers are switched off. both amplifiers are switched off. both amplifiers are switched off.
We have provided your MONOLITH IIIx
CROSSOVER with the proper IEC
standard 3-conductor power cords with
3-prong grounding plug. This cord
should be firmly inserted into the AC
power receptacle located on the rear
panel of the crossover, then to any
Signal Connection Signal Connection Signal Connection Signal Connection Signal Connection
Insert your pre-amps' output cables into
the crossovers'
INPUT jacks, then
connect your low-pass amplifiers' input
cables to the crossovers' LOW OUT-
PUT jacks, and your high-pass amplifi-
ers' input cables to the
HIGH OUTPUT jacks.
Plug in AC mains only after all Plug in AC mains only after all Plug in AC mains only after all Plug in AC mains only after all Plug in AC mains only after all
signal connections have been
signal connections have been signal connections have been signal connections have been signal connections have been
made and you have verified that made and you have verified that made and you have verified that made and you have verified that made and you have verified that
both amplifiers are switched off.
both amplifiers are switched off. both amplifiers are switched off. both amplifiers are switched off. both amplifiers are switched off.
Next, connect the speaker leads from
the high-pass amplifier to the HI
SIGNAL INPUTS on the back of the
MONOLITH III. Then connect the low-
pass amplifier to the LO SIGNAL
INPUTS. Please refer to the pictorial
diagram,
Figure 4 , at right.
Figure 4 Figure 4 Figure 4 Figure 4 Figure 4: MONOLITH IIIx CROSSOVER connection.
convenient AC wall outlet. For absolute
protection,
do not defeat the power plug
ground. This provides powerline
grounding of the
MONOLITH IIIx CROSS-
OVER chassis and will protect you from
electrical shock.
We do not recommend the replacement
or use of "deluxe" or "super" AC power
cords. Many of these designs eliminate
the ground prong of the male plug and
therefore do not follow IEC convention
standards. As such, they present the
possibility of shock hazard.
Your MONOLITH IIIx CROSSOVER has no
power switch as it has been designed
to remain on continuously and should
remain connected to a continuous AC
power source.
Your crossover is wired for the power
service supplied in the country of
original consumer sale unless manu-
factured on special order. The AC
power rating applicable to a particular
unit is specified both on the packing
carton and on the serial number plate
attached to the crossover.
