NOTE: The service indicator must be green before proceeding.
4) Your device is ready to be repacked (see Repacking p. 13).
Usage Below Freezing
When the temperature is below freezing, the Inflatable PFD should
be worn partially inflated because a fully discharged cylinder may not
quickly or adequately inflate your Inflatable PFD. Under these conditions
use the oral inflator to adequately top-up the PFD, after CO2 inflation.
WARNING: CO2 inflation could over-pressurize and damage your
Inflatable PFD if already fully inflated.
Re-arming Your PFD (MD2085)
NOTE: A re-arm kit (MA7203) is required for this procedure.
IMPORTANT: Follow instructions in the exact sequence below.
1) Open inflator cover flap so that manual inflator is exposed (Fig. 7).
2) Remove the cylinder/bayonet assembly by rotating counterclockwise
and then pull out. Discard the used cylinder/bayonet assembly.
3) Check the new cylinder/bayonet assembly to ensure the o-ring is in
place and the sensor ring is attached (Fig. 10). Ensure that the CO2
cylinder has not been pierced (Fig. 10).
Inflatable PFD Owner’s Manual 8
Dust cap
position for
deflation Dust cap
in stowed
position
Oral Inflator
FIGURE 6
Cap In
Deflate
Position
FIGURE 5
