USW-1 Specifications
Acoustical – USW-1/B-2EX System
Frequency Response
1 40-100 Hz +4 dB
Maximum SPL 2
Continuous 130 dB
Peak 135 dB
Acoustical Crossover Frequency 100 Hz
USW-1 Loudspeaker
Transducers
(2) MS-15 15-inch cone, 8 ohms per driver
Enclosure 5 cu. ft. vented, multi-ply Finnish birch
Finish Black textured or weather protected (optional)
Protective Grill Perforated steel screen, charcoal-grey foam covering
Connector EP-4 male, EP-5 male (Europe only)
Rigging (optional) Aircraft pan fittings, 3 ⁄
8
" - 16 or M-10 nut plates
Physical Dimensions 31" W x 21 1 ⁄ 2 " H x 21 1 ⁄ 2 " D with grill frame and foam
Weight 115 lbs. (52.2 kg)
B-2EX Control Electronics Unit
Input Type
Balanced (active), 47k ohms
Output Type Active push-pull, will drive 600 ohms
Maximum Input/Output Level
Balanced +26 dBu
Unbalanced +20 dBu
Hum and Noise 3 -90 dBV
Dynamic Range >110 dB
Sense Input 10k ohms true differential, opto-isolated
Driver Protection Circuitry RMS limiter, switchable excursion limiter
Indicators
Limit Red LED
Excursion Red LED
Sense Green LED
Power Green LED
Controls
Front Panel Input level control, AC on/off switch
Preset Panel Safe switch, Crossover Bypass switch
Connectors
Balanced Inputs/Output 3-pin XLR (A-3)
Sense Inputs Banana jacks
Power 120/240V AC, 50/60 Hz (rear-panel switchable)
Physical Dimensions 19" W x 1 3 ⁄ 4 " H x 7 3 ⁄ 4 " D
Weight 8 lbs. (3.25 kg)
Note 1:
Measured 1 meter on-axis,
half-space conditions,
pink noise input, in third-
octave bands.
Note 2:
Loudspeaker driven by power
amplifier rated at 400 W into
4 ohms, weighted noise
signal source.
Note 3:
“A”-weighted, unbalanced.
