MicroNet Technology SP616EB - Manual (Page 6)

5
Specifications
Standard
IEEE802.3, IEEE802.3u, IEEE802.3x,
compliant
Interface 16 * 10/100M RJ-45 ports
Cable Connections
10BASE-T: Cat. 3, 4, 5 UTP/STP
100BASE-TX: Cat. 5 UTP/STP
MAC address 8K
Buffer Memory 160K Byte for the whole system
NWay Protocol
Network speed:10Mbps and 100Mpbs
Duplex mode: Full and Half
Uplink Auto Uplink (Auto MDI / MDI-X)
Filtering/Forwarding
Rate
10Mbps: 14,880pps/14,880pps
100Mbps: 148,800pps/148,800pps
Emission FCC Class A, CE
Operating Temperature 0
o
- 40
o
C (32
o
- 104
o
F)
Operating Humidity 10% - 90% (Non-condensing)
Dimension (mm) 267 Ч 161 Ч 44
Weight (kg) 1.2
Power Supply
100 ~ 240V AC, 50/60Hz
Full range internal power supply
