Compact Tactical Life Preserver Owner’s Manual 6 7 Compact Tactical Life Preserver Owner’s Manual
7) Refold the Inflatable PFD in accordance with the Repacking section
(p. 12).
YOUR MD3095 IS NOW READY FOR USE
Deflating the LP
To deflate the life preserver, reverse the oral-inflation tube dust cap and
insert it into the valve or depress valve with fingertip (Fig. 5).
The dust cap will not lock in the deflate position so it is necessary to
hold it in place (Fig. 5). Gently squeeze the cell until all air or gas has
been expelled. Put the inflation tube dust cap back in its normal position
on the oral inflation tube (Fig. 5).
Cap In
Deflate
Position
FIGURE 10
Repacking Your MD3090 and MD3095
Before repacking, completely deflate the inflation cell. Force excess air
out through the inflation tube (Fig. 7). Do not wring cell. Put the inflation
tube cap back in the stowed position (Fig. 5).
NOTE: Before following the repacking sequence, be sure to
properly re-arm your MD3090 or MD3095 LP.
1) Fold lapels (A) across the front along the dotted line shown in Fig.
11.
2) Fold side (B) inward along dotted lines. Secure with Velcro™ (Fig.12).
3) Fold outer lapel (C) and secure Velcro™ (Fig. 13). Your MD3090 or
MD3095 will look as illustrated in Fig. 14.
