*Important: Before beginning any of the following,
disconnect the negative battery terminal to prevent an
accidental short circuit.
INSTALLING THE INTERFACE
From the 22 way harness:
Connect the Black wire with the ring terminal to the back of the aftermarket radios chasis •
Connect the 3.5mm jack to your aftermarket radios steering wheel control input (if •
equipped)
From the 30 way harness:
Connect the Black wire to the ground wire of the aftermarket radio •
Connect the RCA’s on 8 pin harness to the AUX in on the aftermarket radio (if equipped) •
The XIA-LCD is need to view Satellite stations (sold separately)
Connect the Yellow wire to the constant wire of the aftermarket radio. •
The GMLAN11-100 comes set up for amplified systems. If the vehicle is not amplified
disconnect the 4 pin harness located between the 30 way and 22 way connector.
Connect the supplied 4 pin speaker harness and connect the following:
Connect the Violet wire to the right rear positive wire of the aftermarket radio •
Connect the Violet/Black wire to the right rear negative wire of the aftermarket radio •
Connect the Green wire to the left rear positive wire of the aftermarket radio •
Connect the Green/Black wire to the left rear negative wire of the aftermarket radio •
INSTALLING THE GMLAN11-100
With all the connections completed, plug the 20, 22, and 8 pin harnesses into the GMOS- •
100i (sold separately).
