STANDING PILOT – MILLIVOLT CONTROL
ILLUSTRATED PARTS LISTS
Item Description
Qty
MDV500NV
MDV500PV
MDV600NV
MDV600PV
1
Gas Valve Assembly
1
37D0117
37D0118
37D0117
37D0118
2
2C
2I
2T
Pilot Assembly
Replacement Thermocouple
Replacement Igniter and Wire
Replacement Thermopile
1
1
1
1
37D0018
37D1067
37D1069
37D1068
37D0019
37D1067
37D1069
37D1068
37D0018
37D1067
37D1069
37D1068
37D0019
37D1067
37D1069
37D1068
3
Burner Tube
1
56D2175
56D2175
56D2175
56D2175
4
Flex Hose with Shutoff Valve
1
69D0030
69D0030
69D0030
69D0030
5
Rocker Switch
1
41D0048
41D0048
41D0048
41D0048
6
Piezo Igniter
1
14D0503
14D0503
14D0503
14D0503
7
Injector
1
57D1030
20H3144
56D0614
57D0680
8
Burner Assembly
1
75D2509
75D2509
75D2509
75D2509
9
Venturi
1
45D0600
45D0600
45D0600
45D0600
10
Wire Assembly
1
44D0500
44D0500
44D0500
44D0500
10
Wire Assembly
1
44D0501
44D0501
44D0501
44D0501
Accessories
11
Thermostatic Remote Control
1
RCST/RCT/
WWTD/WWTA
RCST/RCT/
WWTD/WWTA
RCST/RCT/
WWTD/WWTA
RCST/RCT/
WWTD/WWTA
12
On/Off Remote Control
1
RCB/RCBE/
RCMT/WMTD
RCB/RCBE/
RCMT/WMTD
RCB/RCBE/
RCMT/WMTD
RCB/RCBE/
RCMT/WMTD
13
Full function remote control
1
RCSTEB/
RCSITE
RCSTEB/
RCSITE
RCSTEB/
RCSITE
RCSTEB/
RCSITE
14
Wall Switch
1
MVWS
MVWS
MVWS
MVWS
15
Wired Thermostat Kit
1
WT
WT
WT
WT
Conversion Kit (Not Shown)
500 Conversion NG to LPG
500 Conversion LPG to NG
600 Conversion NG to LP
600 Conversion LP to NG
1
1
1
1
SCK500CKP
—
—
—
—
SCK500CKN
—
—
—
—
SCK600CKP
—
—
—
—
SCK600CKN
