TURN SigNAL/LighTiNg CoNTRoL LEvER
• Rotate the outer knob up to the first position for tail, parking and
dashboard lights.
• Rotate the outer knob up to the second position for tail, parking,
dashboard, and headlights.
• Rotate the outer knob up to the third position for AUTO.
• Rotate the inner ring to turn on the fog lights.
• Push the lever away from you to turn high beams on.
• Pull the lever back one position to turn high beams off. Pull the
lever all the way back and release to flash the high beams.
AUTo
With the headlight switch in AUTO and the ignition ON, the light sensor
determines the surrounding lightness or darkness and automatically turns
the headlights on or off, and adjusts other exterior lights and dashboard
illumination. The setting can be adjusted by the dealership for lighter or
darker conditions.
outer Knob
inner Ring
fog Lights
