Page 6

2
SECTION 1
DESCRIPTION
PS540 SERIES OVEN SPECIFICATIONS
Conveyor Belt Width
32
″ (813mm)
Heating Zone Length
40-1/2
″ (1028mm)
Baking Area Square Feet
9 sq. ft. (0.84 sq. m.)
Overall Dimension
Standard Single Oven w/Legs
80
″ (2032mm) L ×
61-5/16
″ (1557mm) W ×
47-5/16
″ (1202mm) H ×
Overall Dimension
Double Oven
80
″ (2032mm) L ×
61-5/16
″ (1557mm) W ×
60-15/16
″ (1548mm) H x
Overall Dimension
Triple Oven
80
″ (2032mm) L x
61-5/16
″ (1557mm) W ×
77-1/2
″ (1969mm) H ×
Weight of Single Oven
925 lb (419kg)
Shipping Weight
1,100 lb (498.3kg)
Shipping Cube
Approx. 132 ft
3
(3.74 m
3
)
Operating Range
27 kW/hr)
Maximum Operating Temperature
550°F (287°C)
Warm-up Time
15 min.
Recirculating Air Fan
One fan at 2300 RPM
Air Velocity
3000 fpm (1524 cm/sec) (Average)
Bake Time
3 min. 0 sec. Bake Time minimum
30 min. 0 sec. Bake Time maximum
SERIES PS540 ELECTRICAL SPECIFICATIONS
Main Blower &
Control Circuit
Phase
Frequency
Amperage
Poles
Wires
Elements Voltage
Voltage
Draw
208-240V
208-240V
3 Ph
50/60 Hz
100 Amp
4 Pole
4 Wire
(3 hot, 1 grd)
HEATER AMPERAGE
Voltage
kW
Amp
208
27
75
240
27
65
380-400V
208-240V
3 Ph
50/60 Hz
50 Amp
4 Pole
5 Wire
(3 hot, 1neut, 1 grd)
HEATER AMPERAGE
Voltage
kW
Amp
380-400
27-29.9 40-44
400V
208-240V
3 Ph
50/60 Hz
50 Amp
4 Pole
5 Wire
(3 hot, 1neut, 1 grd)
HEATER AMPERAGE
Voltage
kW
Amp
400
27
32.5
NOTE
Wiring Diagrams are contained in Section 7 of this Manual
and are also located inside the oven at the
bottom of the Control Panel
This Manual Must Be Kept For Future Reference
Average Amps
37 37 37
33 33 33
Average Amps
22 22 22
Average Amps
28 28 28
