MITSUBISHI ELECTRIC PK20 - Manual (Page 2)

Unit : mm
L-188-6-B7460-A KYO-0607
New publication, effective Aug. 2006
Specifications subject to change without notice.
Screen
Diagonal size Width (W) Height (H)
Distance
from screen
(D)
Distance from
optical axis
to the bottom
of screen (Ho)
inch cm inch cm inch cm inch cm inch cm
Screen size chart
Input/Output Terminal
Dimensions
Screen size and Projection distance
D
(4:3)
(16:9)
To find out more about PK20 and our projectors,visit us at
1
2
3
4
5
6
7
S-Video in
Video in
PC/Component Video input
(mini D-sub 15pin)
SD card reader
Audio out
Audio in
DC IN
HEAD OFFICE: TOKYO BLDG.,2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN
Ho
Wo
H
W
Specifications
PK20
0.55" DMD
800 x 600 (Total 480,000 pixels)
25lm (High brightnessmode)
1000 : 1 (on/off)
12" - 60"
LED, Life Time : over 10000hrs (on an average)
Resolution ; 640 x 400 - 1024 x 768, True 800 x 600, Sync on Green available
NTSC / NTSC 4.43 / PAL (including PAL-M , N) / SECAM / PAL-60
Component Video ; 480i/p(525i/p), 576i/p(625i/p), 720p(750p),
1080i (1125i 60Hz) , 1080i (1125i 50Hz) ,
[1080i (1250i 50Hz) is not available]
RGB ; mini D-sub 15pin x 1
Video ; RCA x 1 + S-VIDEO x 1
DC power input jack, SD card slot
Audio : Stereo mini jack ( f 3.5mm) x 1
Audio : Stereo mini jack ( f 3.5mm) x 1
1W
Format:JPEG/MPEG-1/MPEG-4/MOTION JPEG
36W (Standby mode ; 1W) without battery
123 x 48 x 97mm (excluding height adjustment)
510g without battery
AC 100 - 240V, 50/60Hz for AC adaptor, 15VDC for main unit
30 dBA
Model
Display technology
Resolution
Brightness
Contrast ratio
Picture size
Light source
Computer compatibility
Video compatibility
Input terminals
Output terminal
Audio speaker
SD card viewer
Power consumption
Dimension (W x H x D)
Weight
Power supply
Fan noise
Tri-pod attachment
Supplied Accessory
BT-PK20R
(Battery) 123 x 24 x 97 mm
350g
120 minutes (with Low mode)
Optional Accessory
Demension
Weight
Operating hours
123
97
48
PK20
PK20
Top view Bottom view
Front view Side view
* SDHC is not intended. * Some JPEG and MPEG files including sound are not supporting.
