Installation examples - venting sys-
tem with flexible hose
Window vent
1. Window vent kit (fitted in a "plexi-
glass" pane)
(separate fitting instructions are sup-
plied with the Miele window vent kit)
2. Adapter for flexible hose
Connection to an exhaust flue
1. Pipe with connection piece
(= supplied with the Miele wall vent
kit)
2. Adapter for flexible hose
3. Exhaust flue insulated against damp
The ducting must not be vented
into a chimney or vent flue which
is in use, nor should it be con-
nected to ducting which ventilates
rooms with fireplaces.
