INTERFACE COMPONENTS
TOOLS REQUIRED FOR INSTALLATION
•A) 4 pin harness with stripped leads •B) 22 pin to 30 pin GM harness •C) 16 pin backup camera harness
•D) 16 pin RSE harness
•Cutting Tool •Tape •Crimping Tool •Connectors (I.E. butt-connectors, bell caps, ECT…)
