PAGE 21
4 OHM 4 OHM 8 OHM
Partial back view of amplifier
8 Ohm Cabinet 8 Ohm Cabinet
SERIES BOX
16 Ohm
8 Ohm 8 Ohm
8 Ohm Cabinet
10
SAFE MISMATCH
12
4 OHM 4 OHM
Partial back view of amplifier
16 Ohm Cabinet 16 Ohm Cabinet
11
8 OHM
8 Ohm Cabinet
16 Ohm Cabinet 16 Ohm Cabinet
4 OHM 4 OHM 8 OHM
Partial back view of amp
PARALLEL BOX
8 Ohm
16 Ohm 16 Ohm
WIRING SCHEMES...Amplifier to Speaker Cabinets
CORRECT MATCH
SAFE MISMATCH
