MARMITEK GIGACAM & MEGACAM
WWW.MARMITEK.COM WWW.MARMITEK.COM
22322 / 161104
GIGACAM 4 SET
Wireless surveillance camera for indoor and
outdoor use.
• Image and sound.
• Easy to connect to your TV or VCR.
• Receiver automatically switches between up to 4 cameras.
HOW DOES IT WORK?
The set consists of a
wireless colour camera
and a receiver.
Install the camera wherever
you want, in- or outside.
Then connect the receiver, using the cable included, to the
Scart connection on your TV or VCR. The camera will transmit
the images and sound to the receiver, wirelessly, even through
walls and ceilings. Power adapters for the camera and receiver
are included.
WANT TO CONNECT MORE CAMERAS?
You can add a maximum of 3 extra wireless cameras to extend
the GigaCam 4 set. With multiple cameras the receiver will
automatically switch between the connected cameras, using an
interval of 4 or 8 seconds.
1 2 3 4
) )
) )
) )
) )
)
Model
System:
Range:
Connection:
Suitable for outdoor use:
Suitable for multiple
cameras:
Sound:
Colour:
Min. Illumination:
Power:
Dimensions:
Operational temperature:
Accessories included:
Cameras available
separately:
GigaCam 4 Set
2.4 GHz wireless
100 m free field, 15-30 m
through walls and ceilings
Scart
Yes, splash-waterproof (IP44)
suitable for sheltered
mounting outdoors
Yes, max. 4 with automatic
switch (4 to 8 seconds)
Yes (built-in Electret
microphone)
Yes (1/3” CMOS) PAL
3 lux
12VDC, 500mA
230V/50Hz power adapter
(included)
Camera: 130x60x72mm
Receiver: 165x95x50mm
-10º/+40º C
Receiver, Scart cable, power
adapter, wall bracket
Wireless colour camera,
identical to camera in the
set.
Set can be extended to a
maximum of 4 cameras.
Wireless Black/White
Night Vision Camera
with extremely light-sensitive
lens and built-in night-view
LEDs, for use in unlit places.
MegaCam 1
Wired
N/A
RCA plugs + Scart
Yes, splash-waterproof
(IP44) when in a sheltered
place outdoors
N/A
Yes (built-in Electret
microphone)
Yes (1/3” CMOS) PAL
3 lux
12VDC, 500mA
230V/50Hz power adapter
(included)
130x60x72mm
-10º/+40º C
15 m cable, power adapter,
wall bracket, Scart adapter
N/A
N/A
) )
)
MEGACAM 1
Camera with cable connection for indoor and outdoor use.
• Image and sound.
• Easy to connect to your TV or VCR.
• Including 15 m cable.
AVAILABLE
• GigaCam 4 (set with camera and receiver) UK. Art. No. 09622 / EU. Art. No. 09619 • Extra colour camera GigaCam 4 UK. Art. No. 09624 / EU. Art. No. 09621
• MegaCam 1 (wired camera) UK. Art. No. 09653 / EU. Art. No. 09635 • Extra black/white “Night Vision” camera GigaCam 4 UK. Art. No. 09626 / EU. Art. No. 09623
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
HOW DOES IT WORK?
The colour camera can be installed in- or outside. The cable (15 m)
has RCA plugs for both image and sound and a connector for the
power adapter. Connect the camera to your TV or VCR (or a PC
with video In). A Scart adapter is included.
