get into it!
# Component Identification Qty.
1 HK TM 12 Jets 24
2 HK TM 16 Jets 4
4 HK TM 8 Neck Jets 2
5 Bathers Control Panel 1
6 IR Sensor 1
7 Filter Canisters 2
8 Suction Fittings 4
9 Floor Drain 1
10 Light 1
11 Neck Jet Valve 1
12 Ozone Injector Fitting 1
13 Spa Frog ® 1
14 Spa Frog ® Return Fitting 1
Physical Specifications Size
Dimensions 84" x 84"
Height 34"
Interior Depth 32.5"
Seating Positions 6/7
Weight Dry/Lbs. 780
Weight Full/Lbs. 4032
Water Capacity/Gallons 390
Total Therapy Jets 30
Use the Bather’s
panel to set the
temperature,
select the
filtration, and
turn on the jets
and lights.
This valve
controls the
water flow of
the neck jets.
5
11
18
the 630
