13
REF.
NO.
PART
NO. DESCRIPTION
1 684-04027 Auger Ass'y 21" complete w/Solid Shaft
2 684-04025 Auger Ass'y 21" w/Solid Shaft
3 710-0896 Hex Screw AB:1/4-14 x 0.625”
4 735-04032 Rubber Spiral
5 735-04033 Rubber Paddle
6 684-04028 Auger Housing Ass’y 21”
7 710-0134 Carriage Bolt 1/4-20 x .62” LG
8 710-0167 Carriage Bolt 1/2-20 x .50 LG
9 710-0323 Truss Mach Scr 5/16-18 x .75
10 710-0352 Hex "B" Tap Scr. 1/4-14 x .375" LG
11 710-0597 Hex Screw 1/4-20 x 1.00 Gr. 5
12 710-1005 Hex Tap Scr. 1/4-14 x .50" LG.
13 710-0642 Hex Tap Scr. 1/4-20 x .75"
14 712-3027 Hex Flange Nut, 1/4-20
15 736-3090 Flat Washer .260 x .720 x .060
16 726-0299 Push Cap x 1/2" Rod
17 731-1033 Shave Plate 2.66 x 19.88 Double
18 732-0357A Extension Spring .33 OD x 1.12 Lg.
19 736-0176 Flat Washer .265 ID x .938 OD x .120
20 736-0326 Flat Washer .510 ID x 1.00 OD x .125
22 741-0919 Ball Bearing
23 741-0600 Ball Bearing 17 x 40 x 12
24 746-04091 Clutch Cable
25 7468-0234 Shoulder Spacer .25 THK
26 749-04114 Lower Handle
27 750-04230 Flange Spacer
28 790-00062 Belt Keeper
29 784-5174 Bearing Cup
30 790-00039 Idler Bracket w/Brake
31 790-00045 Belt Cover
32 710-0487 Carriage Bolt 5/16-18 x 2.0 Gr. 1
33 720-0284 Handle Knob Assembly 5/16-18
34 725-0157 Cable Tie
35 736-0451 Saddle Washer .320 ID x .93 OD
36 747-04165 Bail
37 749-1092A Upper Handle
38 734-04070 Wheel-3 spoke, 7 x 1.61
39 684-04043 Shroud Ass’y 3.5 HP
** 684-04044 Shroud Ass’y 4.5 HP
Models 140, 150, & 160
40 710-1882 Hex Flange Screw 5/16-18 x 1.50 Gr. 5
41 710-1003 Hex Wash B-Tapp Scr #10-16 x .625" Lg.
42 712-0252 Hex Nut 5/8-32 x .12 Special
43 712-3010 Hex Nut 5/16-18 hd. Gr. 5
44 725-0201 Ignition Key
45 725-2018 Key Switch-Electric Start
46 731-1133C Plastic Cap 1.75 Dia x .72
47 736-0119 L-Wash 5/16 ID
48 736-0225 L-Washer Internal .625 ID x 1.058 OD
49 7512B1476 Primer Button
50 710-0157 Hex Screw 5/16-24 x .75 Gr. 5
51* 710-0805 Hex Bolt 5/16-18 x 1,50" Lg. Gr. 5
** 710-3025 Hex Screw 5/16-18 x .625 Gr. 5
52 726-0205 Hose Clamp
53 736-0242 Cupped Washer .340 ID x .872 OD x .060
54 747-04169 Gas Tank Wire Support
55* 750-0589 Spacer .325 ID x .625 OD x .88 Lg.
56* 750-0716 Spacer
57 751-0535-17 Fuel Line 17" Lg.
58 751-0603 Cap-Fuel
59 751-10023 Fuel Tank 2 Quart
60 754-0101A V-Belt 1/2 x 35" Lg.
61 756-04060 Pulley Half .625 ID x 2.35 OD
62 756-0475 Pulley1/2 V x 1/2-20 x 6.0
63 790-00048 Mounting Bracket Support
64 7519630 Recoil Handle
65 712-3004A Hex Flange L-Nut 5/16-18 Gr. 5
66 731-2113B Fuel Plug 1.745 Dia x .75 w/Symbol
67 7511824110 Choke Lever Knob
68* 710-04187 Hex Scr. 1/4-15 x .50
** 710-1268 Hex B-Tapp Wash Scr.#10-16 x .375
69 736-0362 Flat Washer .320 ID x 1.25 OD
70 736-0400 Flat Washer .194" ID x .62" OD x .063
71** 629-0236 Cord-Extension 110V 3M 2 Prong
72* 736-0337 Flat Washer, 5/8 ID x 1.0 OD
73 790-00059 Bracket, Support Gas Tank
74 790-00047 Bracket, Engine
75 710-0654A Screw 3/8-16 x 1.00
REF.
NO.
PART
NO. DESCRIPTION
*Model 140 only
**Model 150 & 160
IMPORTANT: For a proper
working machine, use
Factory Approved Parts.
V-belts are designed to
engage and disengage
safely. A substitute (non
OEM) V-belt can be
dangerous by not
disengaging completely.
NOTE: Snow thrower features/components vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
