6 Pulsar EX Rack : 86-153500-00 MGE UPS SYSTEMS
Pulsar EXB20/30 Extended Battery (See options for battery extension module on page iii.)
rear view
18
CIRCUIT
BREAKER
120Vdc/40A
19
23
Volt: 96Vdc == 20A
Volt: 96Vdc == 20A
22
20
21
