Wiring 5-2
JAMMA Chart
Function Wire Color Pin Function Wire Color Pin
Ground Black A Ground Black 1
Ground Black B Ground Black 2
+5VDC Red C +5VDC Red 3
+5VDC Red D +5VDC Red 4
-5VDC Yellow E -5VDC Yellow 5
+12VDC Orange F +12VDC Orange 6
Key N/C H Key N/C 7
Coin Counter 2 Brown-Red J Coin Counter 1 Brown 8
Not Used N/C K Not Used N/C 9
Speaker -, Left Brown-Gray L Speaker +, Left Red-Gray 10
Speaker -, Right Brown-White M Speaker +, Right Red-White 11
Video Green Yellow-Green N Video Red Yellow-Red 12
Video Sync Yellow-White P Video Blue Yellow-Blue 13
Service Credits White-Gray R Video Ground Yellow-Black 14
Slam Tilt Black-Green S Test Black-Blue 15
Coin 2 Black-Red T Coin 1 Black-Brown 16
2 Start Violet-White U 1 Start White 17
2 Up Violet-Black V 1 Up White-Black 18
2 Down Violet-Brown W 1 Down White-Brown 19
2 Left Violet-Red X 1 Left White-Red 20
2 Right Violet-Orange Y 1 Right White-Orange 21
2 Button A Violet-Yellow Z 1 Button A White-Yellow 22
2 Button B Violet-Green a 1 Button B White-Green 23
2 Turbo Violet-Blue b 1 Turbo White-Blue 24
Not Used Violet c Not Used White-Violet 25
Not Used N/C d Not Used N/C 26
Ground Black e -5V Ground Yellow-Brown 27
Ground Black f Ground Black 28
Solder Side of Circuit Board Component Side of Circuit Board
Control Panel Wires That Aren’t Part of Main JAMMA Harness
Function Wire* SIO Bd, P7- Function Wire* SIO Bd, P14-
4 Digital Ground Blk 1 3 Digital Ground Blk 1
+5 Volts Red 2 +5 Volts Red 2
Unused NC 3/4/5/15 Unused NC 3/4/5/15
4 Start Gry-Wht 6 3 Start Blu-Wht 6
4 Stick Up, Bit 0 Gry-Blk 7 3 Stick Up, Bit 0 Blu-Blk 7
4 Stick Down, Bit 1 Gry-Brn 8 3 Stick Down, Bit 1 Blu-Brn 8
4 Stick Left, Bit 2 Gry-Red 9 3 Stick Left, Bit 2 Blu-Red 9
4 Stick Right, Bit 3 Gry-Orn 10 3 Stick Right, Bit 3 Blu-Orn 10
4 Button A Gry-Yel 11 3 Button A Blu-Yel 11
4 Button B Gry-Grn 12 3 Button B Blu-Grn 12
4 Button C, Turbo Gry-Blu 13 3 Button C, Turbo Blu 13
4 Button D (N/U) Gry-Vio 14 3 Button D (N/U) Blu-Vio 14
*Abbreviations: Bd = Board; NC = Not Connected; Blk = Black; Brn = Brown; Orn = Orange;
Yel = Yellow; Grn = Green; Blu = Blue; Vio = Violet; Gry = Gray; Wht = White.
