Unit:mm in.
L-188-6-B7327-A KYO-0603 Printed in Japan(MDOC)
New publication, effective Mar. 2006
Specifications subject to change without notice.
SL6U
Specifications
Screen size and Projection distance
Input and Output Terminals
Dimensions
Top view
Bottom view
As seen from the side
Side view
Front view
USB terminal for mouse control
Serial terminal RS-232C(8pin)
PC / Component Video output
(mini D-sub 15pin)
PC / Component Video input
(mini D-sub 15pin)
S-Video / Video / Audio input
1
2
3
5
4
*
All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
SL6U
0.6ÓPolysillicon TFL LCD 3
480,000pixels 3(total 1,440,000pixels), 600video lines
1700lm
400 : 1(on/off)
40У ~ 300У(100У=3.0m)
PC: mini D-sub 15pin 1
Video: RCA 1 S-video 1, Audio: RCA (L,R) 1
RGB: mini D-sub 15pin 1,
RS-232C(8pin) 1,(USB terminal for mouse control 1)
2W mono
275 70 261mm (excluding height adjustment)
2.7kg / 5.9lbs
AC100 - 240V / 10%, 50/60Hz
VLT-SL6LP
Model
Display technology
Resolution
Brightness
Contrast
Picture Size
PC input terminals
Video input terminals
Output terminals
Communication terminals
Audio speaker
Dimension W H D
Weight
Power supply
Optional lamp
Video compatibility
Computer compatibility
NTSC/NTSC4.43/PAL(including PAL-M, N)/
SECAM/PAL-60 Component Video(480i,576i,480p,
576p,720p,1080i), SCART(RGB 1V sync)
Source lamp
160W (Shut Off Time 5000Hrs) with Low Mode
200W (Shut Off Time 2000Hrs)
640 400~1024 768
True: 800 600, Sync on green available
267 (10.5У)
261 (10.3У)
54.8
(2.2У)
281 (11.1У)
70 (2.8У)
73.5 (2.9У)
48.7 (1.9У)
70
(2.8У)
82
(3.2У)
275 (10.8У)
233.5
(9.2У)
19 (0.7У)
28
(1.1У) 234 (9.2У)
28
(1.1У)
173.5
(6.8У)
126
(5.0У)
116.5
(46У)
10.9
(4.3У)
51
(2.0У)
49 (1.9У)
177.7
(7.0У)
Hd
Lw~Lt
H
The above numbers are approximate, and may be slightly different from the actual measurements.
Screen
Diagonal size
Width (W)
Maximum Zoom Minimum Zoom
Height (H)
inch
Distance from screen (L)
High projected
image (Hd)
inch
cm
inch
cm
cm
inch
1.2
1.8
2.4
3.0
4.5
6.0
7.6
9.1
inch
1.4
2.2
2.9
3.6
5.5
7.3
9.1
-
inch
cm
Screen size chart (4:3 aspect ratio)
m
m
2.2
3.2
4.3
5.4
8.1
10.8
13.5
16.2
5
8
11
14
21
27
34
41
56
85
114
143
215
287
359
-
47
71
95
119
178
238
298
358
61
91
122
152
229
305
381
457
24
36
48
60
90
120
150
180
81
122
163
203
305
406
508
610
32
48
64
80
120
160
200
240
102
152
203
254
381
508
635
762
40
60
80
100
150
200
250
300
SL6U
1 2
5
3
4
