Specifications
Supply Voltage . . . . . . . . 12V DC, Negative Ground
Current Consumption . . Less than 2A
Signal System . . . . . . . . Composite Video 1.0Vp-p 75
Ω
Compatible Discs . . . . . . (1) DVD-VIDEO Disc, 5" (12cm) Single-Sided Single-Layer, 5" (12cm) Single-Sided
Double-Layer, (2) Compact Disc (CD-DA, Video CD), 5" (12cm) Disc
Audio Output Level. . . . . 2 CH 2.0 Vrms @10k Ω
Characteristics . . . . . . . . (1) Frequency Response: 20 Hz - 20 KHz,
(2) Signal to Noise Ratio: 80dB (JIS)
(3) Wow and Flutter: Below Measurable Limits
20
TV Operation
LANGUAGE SETUP
To access the TV Mode press the MODE
button on the remote. The DVD functions
are locked during TV Mode.
Searching Channels
Press MENU (TV SEARCH) button on the
DVD player front panel or MENU on
remote to enter into search mode. On the
remote press
button to auto search
and store TV channels. Press button
to stop the search.
Selecting Channels
1. Press (CH+) button or (CH+)
Button to select a channel up or down.
2. The numeric buttons (0-9) allow you to
select the corresponding channel.
3. Press the digital select button 3D(-/--)
and a numeric button to select desired
channel.
Volume Adjustment
Press on the front panel of the DVD
player or VOLUME +/- buttons on the
remote to adjust the volume level.
Mute
Press the MUTE button to mute the
sound. Press the MUTE again or volume
up/down buttons on the front panel of
the unit or remote for sound to resume.
^
/
^
