SECTION 2 – SAFETY INFORMATION
mod1.1 2/93
Read all safety messages throughout this manual.
Obey all safety messages to avoid injury.
Learn the meaning of WARNING and CAUTION.
1 Safety Alert Symbol
2 Signal Word
WARNING means possible death
or serious injury can happen.
CAUTION means possible minor
injury or equipment damage can
happen.
3 Statement Of Hazard And Re-
sult
4 Safety Instructions To Avoid
Hazard
5 Hazard Symbol (If Available)
6 Safety Banner
Read safety blocks for each sym-
bol shown.
7 NOTE
Special instructions for best oper-
ation – not related to safety.
2
NOTE
ELECTRIC SHOCK can kill.
•
Do not touch live electrical parts.
•
Disconnect input power before
installing or servicing.
WARNING
READ SAFETY BLOCKS at start of
Section 3-1 before proceeding. WARNING
5
4
6
7
1 2
CAUTION
MOVING PARTS can injure.
•
Keep away from moving parts.
•
Keep all panels and covers closed
when operating.
3
Turn Off switch when using high frequency.
Figure 2-1. Safety Information
SECTION 3 – SPECIFICATIONS
Table 3-1. Rack
Specifications Description
Overall Dimensions Height: 48-5/8 in (1.23 m); Width: 63 in (1.60 m); Depth: 40 in (1.02 m)
Required Input Power 230 Or 460 Volts AC; 50/60 Hz; Three-Phase
Weight Net: 850 lb (385.6 kg); Ship: 860 lb (390.1 kg)
Required Welding Power Source 300 Amp XMT With AUTO-LINK Requiring 230 Or 460 Volts Input Power
Capacity 4 Welding Power Sources Maximum
