Manley STINGRAY original version 1997 - 2005 MST User Manual
Page 2
CONTENTS
INTRODUCTION
3
MAINS CONNECTIONS
4
OPERATIONAL NOTES
5
CONNECTING YOUR STINGRAY
6&7
SIMPLE TROUBLESHOOTING
8
FRONT PANEL, LAMP, BACK PANEL
9
TUBE LOCATIONS
10
SIDE PANELS
11
OPTIMIZING YOUR SOUND SYSTEM
12&13
REPLACING TUBES & SETTING BIAS
14&15
CREDITS
16
SPECIFICATIONS
17
WARRANTY
18
WARRANTY REGISTRATION
19
SECTION
PAGE
2
