Macrom M1A.4150 - Manual (Page 11)

Features
RMS Power at 4 ohm Stereo load at 14,4 volts 75 x 4 watts
RMS Power at 2 ohm Stereo load at 14,4 volts 150 x 4 watts
RMS Power at 4 ohm Bridged load at 14,4 volts 300 x 2 watts
THD (total Harmonic Distortion) < 0,1%
Frequency response (+0/-1 dB) 10 - 30,000Hz
Signal to noise ratio > 100dB
Low Input sensitivity 200-8,000mV
High Input sensitivity 1-10V
Input impedance 22k/100 ohm
Crossover type Variable
Crossover frequency & fi lter slop (High-pass) 30 to 600Hz -12dB/octave
Crossover frequency & fi lter slop (Low-pass) 30 to 600Hz -18dB/octave
Line Output 1-1 (with High pass)
Dimension (w * h * d) mm 250 x 55 x 360
10
• Four channel power amplifi er
• 150 watts into 2 ohms load
• 75 watts into 4 ohms load
• High effi ciency TO3PL transistor on amplifi er stage
• Variable 18/12dB/oct Low-High-Band pass x-over on rear section
• Variable 12dB/oct High pass x-over on front section
• In/Out mode selector (2/4 ch In)(ST/Dual mono Out)
• Adjustable x-over from 30Hz to 600Hz
• EBC external bass control on rear section
• Pre-amplifi ed output with High pass crossover option
• PWM Mos-Fet power supply
• 20sq.mm power terminals
Technical data
