MK Sound LCR-55 Mkii - Manual (Page 2)

Bookshelf-75/Center-75/LCR-75/LCR-55 page 2
1. INTRODUCTION..................................................................................................................3
2. PLACEMENT OF YOUR SPEAKERS..................................................................3
3. SPEAKER HOOK-UP..........................................................................................................3
4. BOOKSHELF-75 FRONT BAFFLE FOAM PLUG...........................................................4
5. HIGH-FREQUENCY PRISM SYSTEM
(LCR-55MkII, Center-55MkII) .......................................4
6. OPTIMIZING SPEAKER PLACEMENT..............................................................................5
7. HOME THEATRE USAGE..................................................................................................6
CENTER CHANNEL ..................................................................................................................7
SURROUND CHANNEL .............................................................................................................7
8. SATELLITE/SUBWOOFER PHASING TEST....................................................................8
9. SPEAKER DAMAGE & HOW TO AVOID IT....................................................................9
10. BI - AMPLIFYING YOUR SPEAKERS WITH M&K HIGH-PASS FILTERS....................9
11. M&K 5.1 MULTICHANNEL & PRO-LOGIC SYSTEM SETUP GUIDE......................................10
12. IF YOU NEED SERVICE OR SET-UP ASSISTANCE......................................................12
13. CABINET MAINTENANCE................................................................................................12
14. USE WITH M&K STANDS & BRACKETS..................................................................12
15. SPECIFICATIONS.......................................................................................................12
DIAGRAMS
FIGURE 1 SPEAKER WIRING..................................................................................4
FIGURE 2 SEPARATION BETWEEN LEFT & RIGHT SPEAKERS............................6
TABLE OF CONTENTS
BOOKSHELF-75 OWNERS:
IF YOU ARE USING A SUBWOOFER
DO NOT REMOVE THE SPECIAL FOAM PLUG
ON THE FRONT BAFFLE OF YOUR SPEAKERS.
This special foam plug tunes the perfomance of your loudspeaker system. If you are using
your Bookshelf-75 speaker with a separate subwoofer, leave the plug in place. If you do not
have a subwoofer, you may want to remove the plug, because its removal will produce more
bass output from the Bookshelf-75. See Section 4 on page 4 for more information.
DO NOT DISCARD THE FOAM PLUG
Bookshelf-75/LCR-55MkII/Center-55MkII/LCR-45
