MUTE_LED:

This LED indicates that the Tuning MUTE function has been triggered either by pulling out the Front Panel MAS-

TER PULL MUTE, or by the Rear Panel Function Switch jack. When this LED is illuminated there will be no signal present at the

SPEAKER OUTPUT jacks.

POWER_SWITCH:

This switch delivers the A.C. power to the M6 CARBINE. Make sure the unit is grounded (all three terminals

of the A.C. power cord must be connected whenever possible to avoid injury to the user as well as to the amplifier). Also, make sure

that the proper voltage requirements are present at the A.C. wall socket receptacle.

NOTE:_As a reminder, never alter the A.C. power cord in any way for possible damage to the
amplifier may occur not to mention the possibility of a fire outbreak.

Now that we have reviewed the features and controls on the Front Panel, let’s take a spin around back and
review the interfacing connections.
