Burner touch controls
Burner displays
Timer
m burner power "ON/OFF"
n power selector
o activates the variable or extended
burners
p Variable or extended burner
activated
q Light ring: The number of segments
lit corresponds to the selected power
setting (exception: see "Auto-heat").
r 0
= Ready for use
1 to 12
= Power setting
#
= Residual heat
F
= Fault
(see "Safety cut-out feature")
The timer will automatically turn off the
front left
a and front right f burners.
s Display for:
Timer
or
Fault indicator (if the cooktop is
turned off, see "Automatic reset of
the touch controls")
t Touch controls for timer setting
Guide to the cooktop
11
o
m
n
p
q
r
u
s
t
