4CH STANDALONE DVR
3、INSTALLATION
REAR PANEL
( )
(2) Audio Output.
(3) Video Output : Corresponding to Video Input.
(4) Video IN : Cameras to Video Input.
(5)
1 Audio Input.
Power Input : Please use the power supply attached
Adaptor : DC-12V / 4A
-4-
(1)
(2) (3)
(4)
(5)
DC12V
CH4
CH3
CH2
CH1
VIDEO IN
VIDEO OUT
AUDIO
IN
OUT
