8
Confi guration 2 Instructions
Fitting the Snap Locks and Slider Plate to the Carrycot
Preparation
Make sure you have all the necessary
parts as outlined in this picture.
NB: The sliding plates part kit is
not supplied with a twin carrycot
and will need to be separately
purchased to attach the twin to
a triple stroller. Also note that the
snap locks used in Confi guration 1
are diff erent from those used in this
instruction.
Work out which side you want to
attach the Carrycot to. If you want to position the Carrycot onto the right side of stroller,
put the snap locks onto the right side of the Carrycot and the sliding plate onto the left. To
position the Carrycot onto the left side of the stroller the snap locks go on the left side of
the stroller and the sliding plate on the right.
NB: Left and right are considered from the point of view of the user when they are
pushing the buggy.
Attaching Snap Locks
1. Place one snap lock over hole A. Make sure it is
aligned correctly with the hole in Carrycot.
2. Using Allen key, rotate screw in snap lock in
clockwise direction until screw is tight. Snap lock
will still be able to rotate but is fi rmly attached.
3. Connect second snap lock according to model
directions for Urban or Terrain.
A
PLEASE FOLLOW THESE INSTRUCTIONS IF YOU
ARE FITTING:
a: a Double Carrycot to a Double Stroller
b: a Double Carrycot to a Triple Stroller
c: a Twin Carrycot to a Triple Stroller
›››
SLIDING PLATE PARTS KIT
1 x sliding plate
1 x Allen key 2 x screws
2 x snap locks 1 x cover buttons
1 x screw
PARTS LIST
Carrycot
