MP42 CONFIGURATION GUIDE
FLOOR STAND
Remove the B-Type end caps, brass thumb screws, and
aluminum mounting bracket. Replace the brass thumb
screws in the top of the cabinet and snap an A-Type
end cap into place. Then simply mount the MP42 to the
recommended Studio Tech S1 stands using a 1/4-20 1” long
hex head bolt. (Not Included)
A-TYPE
CAP
STUDIO TECH
S1 STANDS
RECOMMENDED
1/4-20
1” LONG
BOLT
6 9
PAINTING
Carefully remove the spring clip on the back of the grill logo
and remove the logo. Mask the baffle area of the speaker
cabinet out to the grill mounting groove. If you are going to
mount the MP42 using the supplied wall bracket it is best
to also mask off the foam rubber bracket gaskets at the top
and bottom of the speaker cabinet. Almost any type of
paint can be used but best results will be had using a
quick drying enamel or lacquer spray paint. For best results
always follow the paint manufacturers recommendations
for proper application. After painting the cabinet, grill and
applicable end caps allow the paint to dry thoroughly.
GRILL ASSEMBLY
Place the four grill adhesive strips in the groove located at
the outer rim of the baffle. Carefully snap the grill into place
and rotate the logo for proper orientation.
