Philips Magnavox MT1331B3 - Manual (Page 2)

OR
ANT.IN
OR
UHF
VHF
300Ω
75-300
Ω ADAPTER
ANT.IN
H
OOKING
U
P
Y
OUR
TV (A
NTENNA
/C
ABLE
C
ONNECTIONS
)
A combination antenna
receives normal broadcast
channels (VHF 2-13 and UHF
14-69). Your connection is easy
since there is only one 75
Ω
(ohm) antenna jack on the
back of your TV - and that’s
where the antenna goes.
A NTENNA
C OMBINATION UHF/VHF To set the
TV to select only
the channel num-
bers in your area,
see Auto Install
(page 4).
S MART
H ELP
If your antenna has a
round connector (75 Ω),
then you're ready to connect it
to the TV. Go to step 2.
If your antenna has flat
twin-lead wire (300
Ω), you
first need to attach the antenna
wires to the screws on a 300
to 75
Ω adapter (not supplied).
Push the round end of
the adapter (or cable) onto
the ANT(enna) IN jack on
the back of the TV. If the
round end of the adapter or
cable is threaded, screw it
down tight.
Y ou may have two separate
antennas. One antenna is
for VHF channels (2-13) and
the other antenna is for UHF
channels (14-69).
For homes with separate
UHF/VHF antennas, you will
need an optional combiner
before you can connect the
antennas to the TV.
S EPARATE UHF/VHF
300 to 75 Ω
Adapter
Combination
VHF/UHF
Antenna
(Outdoor or
Indoor)
Twin-lead
Wire
Round Cable
75 Ω
Back of TV
Back of TV
UHF/VHF
Combiner
(not supplied)
75-300 Ω Adapter
Outdoor UHF Antenna
(Twin-lead 300 Ω)
Outdoor VHF
Antenna
(Twin-lead 300 Ω)
Twin-lead
Wire
Push the round end of the
combiner onto the ANT(enna)
IN jack on the back of the TV.
Attach the separate
UHF and VHF antennas to
the correct screws on the
combiner (not supplied).
Round
End
Outdoor VHF
Antenna
(Round cable 75 Ω)
