4
10) Menu setting commands
(Not executable in stand-by mode, while the Splash screen is projected or the MUTE is executed.)
The menu setting commands are used for the menu setting of this projector. If the personal computer sends the
command without attaching the data code, the projector attaches to the received command it’s current setting
value as the data code and send it back to the PC.
ITEM ASCII HEX VALUE
CONTRAST *1 P 50h
±
30
±
30
±
30 (R from G+Main data+B from G)
BRIGHTNESS *1 Q 51h
±
30
±
30
±
30 (R from G+Main data+B from G)
sRGB SRGB 53h 52h 47h 42h 0 (OFF), 1 (ON)
COLOR MATRIX (MODE) CMT 43h 4Dh 54h 1 (VIDEO), 2 (COMPUTER), 3 (USER), 4 (OFF)
COLOR MATRIX (R, G, B) MRGB 4Dh 52h 47h 42h
±
30
±
30
±
30 (R+G+B)
COLOR MATRIX (Y, C, M) MYCM 4Dh 59h 43h 4Dh
±
30
±
30
±
30 (Y+C+M)
COLOR MATRIX (SATURATION) MSAT 4Dh 53h 41h 54h
±
05
COLOR MATRIX (RGB-TINT) MT 4Dh 54h
±
20
COLOR TEMP. A 41h 1 (STANDARD), 2 (HIGH), 3 (LOW), 4 (USER)
COLOR T 54h
±
10
TINT S 53h
±
10
SHARPNESS R 52h
±
10
GAMMA MODE GS 47h 53h 0 (DYNAMIC), 1 (STANDARD), 2 (THEATER), 3 (AUTO)
AUTO POWER ON APON 41h 50h 4Fh 4Eh 0 (OFF), 1 (ON)
AUTO POWER OFF APOF 41h 50h 4Fh 46h 00 (OFF) , 05, 10, 15, 30, 60
SPLASH SCREEN SS 53h 53h 0 (OFF), 1 (ON)
BACK COLOR BB 42h 42h 0 (BLACK), 1 (BLUE), 2 (LOGO)
MUTE MODE MM 4Dh 4Dh 0 (BLACK), 1 (LOGO)
LAMP MODE LM 4Ch 4Dh 0 (STANDARD), 1 (LOW)
IMAGE REVERSE IR 49h 52h 0 (OFF), 1 (MIRROR), 2 (INVERT), 3 (MIRROR, INVERT)
LENS SHIFT LOCK LSL 4Ch 53h 4Ch 0 (OFF), 1 (ON)
LENS SHIFT RESET LSRST 4Ch 53h 52h 53h 54h
MENU POSITION MP 4Dh 50h 0 (Upper left), 1 (Lower right)
EXPAND MODE EX 45h 58h 1 - 4
FRAME POSITION FM 46h 4Dh 1 - 5
VIDEO SIGNAL VS 56h 53h 0 (AUTO), 1 (NTSC), 2 (PAL), 3 (SECAM) ,
4 (4.43NTSC), 5 (PAL-M), 6 (PAL-N), 7 (PAL-60)
SCART SRT 53h 52h 54h 0 (OFF), 1 (ON)
ANAMORPHIC SC 53h 43h 0 (OFF), 1 (CENTER), 2 (UPPER), 3 (LOWER)
3D CineView LD 4Ch 44h 0 (OFF), 1 (ON)
LANGUAGE LG 4Ch 47h 0 ( ), 1 (English), 2 (Español), 3 (Deutsch) , 4 (Français),
5 (Italiano),6 ( ), 7 ( ), 8 ( ), 9( )
RESET ALL RSTALL 52h 53h 54h 41h 4Ch 4Ch
MEMORY CALL MMC 4Dh 4Dh 43h 0 (AUTO), 1 (USER1), 2 (USER2)
HORIZ. POSITION HP 48h 50h + (increase), – (decrease)
VERT. POSITION VP 56h 50h + (increase), – (decrease)
FINE SYNC. FN 46h 4Eh 00 - 39
TRACKING TRK 54h 52h 4Bh + (increase), – (decrease)
COMPUTER INPUT CIN 43h 49h 4Eh 0 (RGB), 1 (YC B C R /YP B P R )
HOLD HLD 48h 4Ch 44h 0 (AUTO), 1 (ON), 2 (OFF)
HOLD BEGIN HLB 48h 4Ch 42h –01 - –99
HOLD END HLE 48h 4Ch 45h 01 - 99
CLAMP POSITION CLP 43h 4Ch 50h 00 - 63
CLAMP WIDTH CLW 43h 4Ch 57h 01 - 63
HORIZ. PIXELS HPL 48h 50h 4Ch 0000 - 9999
VERT. LINES VLN 56h 4Ch 4Eh 0000 - 9999
VERT. SYNC. VSC 56h 53h 43h 0 (AUTO), 1 (ON), 2 (OFF)
SHUTTER (U) SHU 53h 48h 55h 000 - 383
SHUTTER (L) SHL 53h 48h 4Ch 000 - 383
SHUTTER (LS) SHLS 53h 48h 4Ch 53h 000 - 510
SHUTTER (RS) SHRS 53h 48h 52h 53h 000 - 510
*1) When sRGB is ON, only the main data are effective.
• Some commands are not executed depending on the input signal. The operational restrictions same as
those on the menu setting are applied. Refer to “Menu operation” in the User Manual for more details.
Sending commands Status code from Description
from the PC, etc. the projector
30 30 76 49 0D Command for checking the input terminal
'0' '0' 'v' 'I' ' '
30 30 76 49 76 31 0D Check result ( VIDEO 1)
'0' '0' 'v' 'I' 'v' '1' ' '
The PC sends the command without attaching the data code to it. On the other hand, the projector attaches
to the received command it’s current operating status as the data code and send it back to the PC.
[Example ] When checking the currently selected input terminal (when the INPUT VIDEO 1 is being selected) :
