3-6. Installing Wiring Harness Tab Connectors
Disconnect vehicle wiring harness plug from trailer wiring connector before
beginning installation. Use wiring harness tab connectors only with insulated wires.
NOTE
1
Connector
2
Run Wire
3
Tap Wire
Place unstripped run wire in slotted channel.
Insert unstripped tap wire into other channel
until it hits internal stop.
4
Contact
5
9 Inch Linemans Pliers
Use pliers to push contact down flush with
top of connector.
Close top cover.
Ref. S-0448
1
2
3
4
5
