mermaid ventura 150/170/181/190 TFT Video Models - Users Manual Version 3.0a
___________________________________________________________________________________
Page 5 of 18
5. OSD Key Functions
4-button
OSD Panel
Auto Config:
(Hot key)
Source select:
(Hot key)
Select OSD Menu:
(Hot key)
OSD Menu selected:
= key(s) which are pressed
* When the monitor is turned on, it automatically scans the three different inputs (VGA, CVBS, Y/C) for a valid signal,
It then stops at the first valid input. The scan routine starts from the last used input.
Enter/
Escape
Down
Decrease(-)
Increase (+)
Function Description
Menu (Hot Key)
Activates the OSD
Auto Config (Hot Key) Auto calibrate the monitor for optimal performance
Source Select * When both keys are pressed, the monitor selects the next source
VGA Composite S-Video
Enter/Escape Enters or Escapes the highlighted menu.
Decrease (-) Moves the cursor down to the next menu item
Increase (+) Increases the value of the selected.
Select the next lower level menu.
