4
11) Menu setting commands (Not executable in stand-by mode. Possible only to read during muting.)
The menu setting commands are used for the menu setting of this projector. If the personal computer sends the
command without attaching the data code, the projector attaches to the received command it’s current setting
value as the data code and send it back to the PC.
ITEM ASCII HEX VALUE
CONTRAST *1 P 50h ±30±30±30 (R from G+Main data+B from G)
BRIGHTNESS *1 Q 51h ±30±30±30 (R from G+Main data+B from G)
sRGB SRGB 53h 52h 47h 42h 0 (OFF), 1 (ON)
COLOR MATRIX (MODE) CMT 43h 4Dh 54h 1 (VIDEO), 2 (COMPUTER), 3 (USER), 4 (OFF)
COLOR MATRIX (R, G, B) MRGB 4Dh 52h 47h 42h ±30±30±30 (R+G+B)
COLOR MATRIX (Y, C, M) MYCM 4Dh 59h 43h 4Dh ±30±30±30 (Y+C+M)
COLOR MATRIX (RGB-TINT) MT 4Dh 54h ±20
COLOR TEMP. A 41h 1 (STANDARD), 2 (HIGH), 3 (LOW), 4 (USER)
COLOR T 54h ±10
TINT S 53h ±10
SHARPNESS R 52h ±05
GAMMA MODE GS 47h 53h 0 (DYNAMIC), 1 (STANDARD), 2 (THEATER), 3 (AUTO)
AUTO POWER ON APON 41h 50h 4Fh 4Eh 0 (OFF), 1 (ON)
AUTO POWER OFF APOF 41h 50h 4Fh 46h 00 (OFF) , 05, 10, 15, 30, 60
SPLASH SCREEN SS 53h 53h 0 (OFF), 1 (ON)
BACK COLOR BB 42h 42h 0 (BLACK), 1 (BLUE), 2 (IMAGE)
MUTE MODE MM 4Dh 4Dh 0 (BLACK), 1 (IMAGE)
LAMP MODE LM 4Ch 4Dh 0 (STANDARD), 1 (LOW)
IMAGE REVERSE IR 49h 52h 0 (OFF), 1 (MIRROR), 2 (INVERT), 3 (MIRROR, INVERT)
MENU POSITION MP 4Dh 50h 0 (Upper left), 1 (Lower right)
EXPAND MODE EX 45h 58h 0 (Expand), 1 (Real)
AUDIO MODE AU 41h 55h 0 (MUTE), 1 (COMPUTER), 2 (VIDEO), 3 (COMPUTER VIDEO)
CINEMA MODE CINE 43h 49h 4Eh 45h 0 (OFF), 1 (AUTO)
VIDEO SIGNAL VS 56h 53h 0 (AUTO), 1 (NTSC), 2 (PAL), 3 (SECAM) ,
4 (4.43NTSC), 5 (PAL-M), 6 (PAL-N), 7 (PAL-60)
SCART INPUT SRT 53h 52h 54h 0 (OFF), 1 (ON)
ANAMORPHIC SC 53h 43h 0 (OFF), 1 (CENTER), 2 (UPPER), 3 (LOWER)
LANGUAGE LG 4Ch 47h 0 ( ), 1 (English), 2 (Español), 3 (Deutsch) , 4 (Français),
5 (Italiano),6 ( ), 7 ( ), 8 ( ), 9( )
RESET ALL RSTALL 52h 53h 54h 41h 4Ch 4Ch
FINE SYNC. FN 46h 4Eh 00 - 31
COMPUTER INPUT CIN 43h 49h 4Eh 0 (RGB), 1 (YC B C R /YP B P R )
HOLD HLD 48h 4Ch 44h 0 (OFF), 1 (ON)
HOLD BEGIN HLB 48h 4Ch 42h 00 - 15
HOLD END HLE 48h 4Ch 45h 00 - 15
Sending commands Status code from Description
from the PC, etc. the projector
30 30 76 49 0D Command for checking the input terminal
'0' '0' 'v' 'I' ' '
30 30 76 49 76 31 0D Check result ( VIDEO 1)
'0' '0' 'v' 'I' 'v' '1' ' '
The PC sends the command without attaching the data code to it. On the other hand, the projector attaches
to the received command it’s current operating status as the data code and send it back to the PC.
[Example ] When checking the currently selected input terminal (when the INPUT VIDEO 1 is being selected) :
10) Reading command diagram
The projectors operating status, such as POWER-ON / OFF and the currently selected input terminal, etc. can
be monitored.
ASCII HEX
Function Data (Receive) Function Data (Receive)
POWER ON vP 1 76h 50h 31h
POWER OFF vP 0 76h 50h 30h
INPUT COMPUTER 1 vI r1 76h 49h 72h 31h
INPUT COMPUTER 2 vI r2 76h 49h 72h 32h
INPUT VIDEO 1 vI v1 76h 49h 76h 31h
INPUT VIDEO 2 vI v2 76h 49h 76h 32h
POWER ON/OFF INPOSSIBLE vPK 0 76h 50h 4Bh 30h
POWER ON/OFF POSSIBLE vPK 1 76h 50h 4Bh 31h
NO SIGNAL SUPPLIED vSM 0 76h 53h 4Dh 30h
SIGNAL SUPPLIED vSM 1 76h 53h 4Dh 31h
