Specifications
■
CONTROL INPUT
Connector
1 x RJ12 (Modular 6P6C)
Physical Layer
RS-422
Data Protocols
Image Video:
Start Bits
1
Data Bits
7
Parity
Even
Stop Bits
1
Baud Rate
38400
TSL v4.0 Protocol:
Start Bits
1
Data Bits
8
Parity
Even
Stop Bits
1
Baud Rate
38400
Pinout
■
MONITOR OUTPUTS
Connectors
4 x RJ12 (Modular 6P6C)
Physical Layer
RS-422
Data Protocol
MEI
Start Bits
1
Data Bits
8
Parity
None
Stop Bits
1
Baud Rate
57600
Pinout
■
NETWORK CONNECTION
Connector
1 x RJ45 (Modular 8P8C)
Physical Layer
10BASE-T or 100BASE-T Ethernet
Data Protocol
TCP/IP
■
ELECTRICAL
Power Consumption
3.0A @ 12VDC (36 W)
Voltage Requirement 12 VDC
V-PS12-5V-1 Power Supply:
Input
100V-240V, 1.5A, 50-60Hz
Output
12VDC, 5A, 60W Max
■
MECHANICAL
Dimensions (w x h x d): 18.96" x 1.72" x 8.37”
Rack Height:
1RU
Weight:
5.5 lbs
Operating Temperature 32°F to 120°F (0°C to 50 °C)
Storage Temperature
-4°F to120°F (-20°C to 50°C)
Compliance
Œ
, FCC-Class A, ANSI-63.4
(Certificates on file)
RoHs
Do not dispose. Return to
Manufacturer or Authorized
Recycle Facility.
Pin No.
Signal
1
N/C
2
Ground
3
Rx+
4
Rx-
5
N/C
6
N/C
Pin No.
Signal
1
Rx-
2
Ground
3
Tx+
4
Tx-
5
N/C
6
Rx+
