Meade Instruments LXD75 User Manual
Page 5
5
Ạ
ạ
Ả
ả
Ấ
Fig. 1e: The LXD75-Series Computer Control Panel (see
2$
above).
Fig. 1d: The LXD75-Series Mount; insert shows opposite side of Mount.
2!
2@
ƿ
1&
1*
1(
2#
2$
2% 2^
2^
2*
2(
2&
3)
3!
3$
ấ
3@
3#
Legend
1. Eyepiece Thumbscrew
2. Eyepiece Holder
3. Eyepiece
4. Viewfinder (VF)
5. VF Collimation Screws
6. VF Front Cell
7. VF Bracket
8. Focus Knobs
9. Corrector/Dust Cover
10. Optical Tube
11. Cradle Assembly
12. Autostar Handbox
13. Cradle Ring Lock Knobs
14. Cradle Rings
15. VF Bracket Screws
16. Focus Lock Knob
17. Dec. Lock
18. Polar VF Cap
19. Dec. Setting Circle
20. Counterweight Shaft Base
21. Counterweight, Lock Knobs
22. Counterweight Shaft
23. Counterweight Safety Cap
24. Computer Control Panel
25. R.A. Motor Drive
26. Latitude Adjustment Handles
27. Azimuth Control Knobs
28. Latitude Dial
29. Polar Alignment VF
30. Polar Alignment Reticle, LED
31. R.A. Setting Circle
32. R.A. Setting Circle Lock Knob
33. R.A. Lock
34. Dec. Motor Drive
35. T-Handle Lock and Shaft
36. Spreader Bar
37. Tripod Mounting Base
38. Tripod Legs
39. Spreader Tension Knob
