3-2. Symbols And Definitions
Tig Welding
Remote Foot/Hand
Control
Stick Welding
High Temperature
Output
Alternating Current
Direct Current
On
Electrode Positive
Electrode
Negative
Do Not Switch
Under Load
Voltage Input
A
Amperes
Off
Electrode
Gas Out
Amperage Control/
Panel
Work
Remote
V
Volts
U
0
Rated No Load
Voltage (Average)
U
2
Conventional Load
Voltage
X
Duty Cycle
I
1eff
Maximum Effective
Supply Current
I
1max
Rated Maximum
Supply Current
I
2
Rated Welding
Current
IP
Degree Of
Protection
1
1
1
1
Single-Phase
Combined AC/DC
Power Source
Percent
U
1
Primary Voltage
Line Connection
Hz
Hertz
SECTION 4 − INTRODUCTION
4-1. Included with Your Unit
1
12 ft (3.7 m) Work Cable
and Clamp
2
150 Amp TIG Torch with
12-1/2 ft (3.8 m) Cord and
Flow-Through
Quick-Connect (50 Hz
models come with 25 ft (7.6
m) TIG Torch)
3
Electrode Holder and
Quick-Connect
4
Gas Hose
5
Gas Regulator (Not
included with 50 Hz
models)
6
“How-To” DVD
7
RFC-14 Foot Control with
20 ft (6 m) Cord (60 Hz
models only. 50 Hz models
come with RCC-14
fingertip control instead.)
8
8 ft (2.4 m) Primary Cord
(Plug supplied with 230
Volt model only)
.
Some assembly is required.
For options and accessories see
back of book or contact your dis-
tributor.
7
2
3
4
5
6
8
1
