^ Feed the ductwork and power cable
through their respective holes in the
ceiling.
If 6" (150 mm) ductwork is not possible
then 5" (125 mm) ductwork can be
used in conjunction with a reducing
collar available from the Miele Technical
Service Department (see "Installation /
Air extraction" for further details).
^ Drill four 3
/
16
" (5 mm) holes in the
ceiling.
The S10 wall anchors included in the
packaging are not for use in
USA/CDN. Be certain that the ceiling
is stable enough to support the
hood.
^ Secure the ducting to the mounting
plate using a hose clip.
Installation
25
